 M-type

  FLAT FILM YARN  (Unsupported)
For Weaving, Making Fancy Yarns, Ribbons and Woven Labels

This item is made of 12 or 24 micron, one-sided Metallized polyester film that is Metallized with aluminum & colour coated with resin by high technique. Other thickness of the polyester film such as 36 & 37 micron can be supplied on request with the minimum quantity to be specified.

THICKNESS
MICRON
WIDTH
INCH
LENGTH(METER PER KG)X1000 COMPOSITION
SILVER GOLD COLOR CLEAR IRISE
12 1/32" 73 67 65 80   PE 100%
1/50" 109 101 99
1/69" 146 135 131 160
1/100" 219 203 198 240
1/110" 236 219 213 257
1/127" 274 270 268
25 1/32" 37 36 35     PE 100%
1/69" 73 71 70
1/92" 102 98 97
1/100" 110 106 105
30 1/32"         35
1/69"         70
1/100"         105
38 1/32" 25 24 23   30
1/69" 49 48 47   60
1/100" 74 72     89
Key to abbreviation
PE = Polyester

Thickness
12 MICRON    = 50GAUGE
25 MICRON    = 100GAUGE
30 MICRON    = 120GAUGE
38 MICRON    = 150GAUGE

Width
1/69"(inch)   = 0.37mm
1/32"(inch)   = 0.79mm
1/92"(inch)   = 0.27mm
1/100"(inch) = 0.25mm
1/110"(inch) = 0.23mm
1/127"(inch) = 0.20mm
Make-Up
100 gram on bobbin (Bobbin size Dia.54mm X Height 63mm)
160 gram on bobbin (Bobbin size Dia.70mm X Height 64mm)
300 gram on bobbin (Bobbin size Dia.83mm X Height 98mm)
